AILESEN(CHANGZHOU)POWER TECHNOLOGY CO.,LTD

 FUEL VALVE TEST DEVICE COMMON FAULTS AND TROUBBLES HOOTING

                                       Model:HDFD1100

1. Unable to build pressure:

1.1 Check whether the fixing screw nut of the fuel valve is tightened (tighten the nut).

1.2. Check whether the test hydraulic oil meets the hydraulic oil specified in this manual (replace the specified oil).

1.3. Check whether the hydraulic oil filter in the oil tank is cleaned at the specified time (replace and clean the oil filter).

1.4. Check whether the oil level in the oil tank is too low (increase the test oil).

2. The fuel valve test device does not work:

2.1. Check whether the air pipe connecting the device is unobstructed (replace the joint and air pipe).

2.2. Check whether there is air pressure in the air pressure regulating valve (3) and the input air meter (6) (replace the air pressure regulating valve).

3. Pressure leakage:

3.1. Check whether there is leakage at the joints inside the test bench (tighten the joints).

3.2. Check whether the return oil valve is leaking (grind the return oil valve stem, replace the return oil valve).

3.3. Check the high-pressure oil pump input and output connectors for oil return (disassemble and clean or replace both connectors).

4. Pressure gauge does not return to zero at zero pressure:

After the pressure on the test bench is completely released, adjust the "0-adj" knob on the rear of the digital display to zero.

Turn clockwise to increase, counterclockwise to decrease. (If there is no response, replace the pressure gauge and pressure sensor).

5. Digital display does not display:

5.1. Check the digital display power input terminals (terminals 1 and 2 are 110VAC; terminals 1 and 3 are 220VAC. Consult the ship's electrical engineer to determine which input terminal to use based on the ship's conditions).

5.2. Check the input terminals for power. If there is power but no display, replace the digital display.

6. Digital display displays garbled data:

If garbled data persists after replacing the pressure sensor, replace the digital display.
